LEGAL ADVICE

It is the customer’s responsibility to check directives and copyright laws before putting this product into service. You, the customer agree to defend, indemnify and hold harmless Aareff Systems Limited, it’s employees and agents, from and against any claims, actions or demands, including without limitation legal and accounting fees, alleging or resulting from improper or unlawful use of this product.

PACKAGE CHECKLIST

A	Minix Neo Z83-4 Intel Mini Computer
B	USB Mini Sound Card
C	1m RJ45 Terminated Network Cable
D	1m Stereo RCA to Stereo 3.5mm Jack Cable
E	100-240V AC to 12V DC Power Supply and Cable

OTHER EQUIPMENT REQUIRED

For this unit to work correctly you need:

• an AC supply of bewteen 100 and 240V;
• a stereo audio feed from the mixer or other studio processing equipment at line level; and
• an internet router with a RJ45 ethernet port and a internet connection with minimum constant upload speed of 200 Kb/s

EQUIPMENT SET UP

This system is literally Plug and Play and very easy to setup. Connect the equipment as shown in the picture. Then connect:

1. The cable marked C into the internet router.
2. The USB sound device marked B with a yellow sticker in the USB port of the MiniX computer marked with a yellow stick
3. The cable marked D into the studio mixer or processer and the microphone input of the USB sound device marked B
4. The power supply marked E into the MiniX computer and the AC power

Now wait about a minute for the whole thing to boot up and lock onto to the server. Go to radio station webpage that we emaled to you and you should hear the audio playing

THAT'S IT, FINISHED !!!!

If you cannot hear audio or have similar problem, contact us and we'll log onto the server and we'll attempt to resolve the problem remotely for you.
