This neat package, INCLUDES our 30W Transmitter Stereo and Audio Processing, 2 Way Stacked Dipole and 20 metres of cable. It is ideal for any low power broadcasters wishing to cover a small complex such as a university complex, hospital grounds, very small village, theme parks etc.
|30W Transmitter Stereo and Audio Processing|
|2 Way Stacked Dipole 88-108 MHz|
|20 Meter Antenna Cable|
|All Interconnectiong Cables|
|Antenna Mounting Brackets|
Most small radio stations and beginners will use this version, this is because it includes audio processing circuitry and suitable limiting to keep the transmitter in compliance with the maximum bandwidth permitted by the international regulations. There is also access to the MPX in and out on the back panel which allows all known RDS units to be connected.
This unit is supplied complete in enclosure fully built and tested. The 100-240V AC model will operate on any mains power supply in the world. Just hook up the power amp to your transmitter drive and power supply. The power output is adjustable from 1 to 30 watts on a internal control.
There are not many complete 2 way stacked dipoles on the market and certainly not at the price we sell this one for. Without a shadow of a doubt, this is the best value for money and performance high gain and full broadband FM 2 way stacked dipole you will find on the market.
Any frequency between 87.5 to 108MHz can be accurately programmed on the internal dip switches accessible from the underside panel in a few minutes. Expensive test equipment is NOT required, set up is a simple task using the LED's on the front panel. The transmitter operates from a 15DC supply or the supplied AC adapter (100 - 250VAC). This makes it suitable for use on a standard power pack or automobile power system anywhere around the world.
20 Meter Antenna Cable - This cable is high quality foam and carries the radio signal 20 meters to the antenna, this would normally be used for stations with towers, or masts of up to 15 meters in height.
On delivery the equipment is ready to plug in and use. This FM transmitter system along with all our other products comes with a limited 2 year warranty (see warranty conditions)
Instructions are supplied to show the station engineer how to set this system to any frequency from 87.5 - 108.0 MHz. However, when we assemble this system we have to test and set it to some frequency, please select the frequency in price panel below that you would like it set to on delivery.
When used with suitable audio limiting equipment, this complete set of equipment used as delivered without any modifications, including it's power supply, the dipole antenna and the 12 metres of antenna cable, complies with New Zealand Radio Communications Regulations (General User Licence for Low Power FM Broadcasting) Notice 2010 Schedule 1 Transmitter Emission Requirements. It also complies with EU Telecommunications ETS 300384, EMC EN 301 489-11 and Safety LVD 2006/95/ and also ITU-R BS.450-3 (11/01) FM Broadcasting at VHF. If you are a novice or beginner and you don't have no knowledge of audio limiting, processing and compression you should purchase the stereo version with audio processing to maintain compliance with the regulations.
